JD Performance F150 Fuel System

Fuel is the foundation of every high-horsepower build.

Whether you're adding boost, switching to E85, or simply planning for future upgrades, the factory fuel system eventually becomes the limiting factor. The JD Performance Solutions Drop-In Returnless Dual Fuel Pump System was designed to eliminate that restriction while maintaining the factory-style operation and drivability Ford owners expect.

Unlike universal solutions that require extensive modification, this system installs directly into the factory fuel tank and retains the OEM siphon system, ensuring consistent fuel delivery even when fuel levels are low. Full PCM-controlled PWM operation allows the system to function exactly as intended, delivering precise fuel pressure control without sacrificing drivability.

Available in two proven configurations, the JD Performance Fuel System gives builders the flexibility to choose the fuel capacity that matches their horsepower goals.

Available Stages:

Stage 1
• Dual GT350 Fuel Pumps
• Supports up to 800 RWHP on E85*

Stage 2
• Dual 2018+ Flex Fuel Pumps
• Supports up to 1,000 RWHP on E85*

Features:

• Direct Drop-In Installation
• Retains OEM Siphon System
• Full PCM PWM Fuel Pump Control
• OEM-Style Plug-and-Play Harness
• Inline Motorcraft Fuel Filter
• Designed for Forced Induction Applications
• Excellent Street Manners and Reliability

Whether you're building a street truck, weekend dragstrip warrior, or a 1,000-horsepower monster, the JD Performance Fuel System delivers the fuel volume, reliability, and OEM-level integration needed to support serious power.

Because running out of fuel is a terrible way to find your limit.

*Horsepower capability may vary based on fuel quality, fuel pressure targets, engine combination, and tuning strategy.

*NOTE: All pump kits are built to order and lead times is generally 4-6 weeks
